42 Commander SE Advanced User Guide
Issue Number: 4
3.5 Menu 5: Machine control
Parameter Range Type Default Setting
5.01 Motor frequency ±[1.06]Hz RO Bi P L3
5.02 Motor voltage 240-480V RO Bi P B
5.03
Total motor power (Output power
from drive)
± P max(kW) RO Bi P B
5.04 Motor rpm ±9999rpm RO Bi P B
5.05 DC Bus voltage
400V units =
0 ~ 830V
200V units =
0 ~ 420V
RO Uni P B
5.06 Motor rated frequency 0 ~ 1000.0 Hz RW Uni
EUR> 50.0
USA> 60.0
BS, MC
5.07 Motor rated current 0 ~ Drive rating RW Uni FLC BS, MC
5.08 Motor rated full load rpm 0 ~ 9999rpm RW Uni
EUR> 1500
USA> 1800
BS, MC
5.09 Motor rated voltage
400V units =
0 ~ 480V
200V units =
0 ~ 240V
RW Uni
EUR> 400V units = 400V
200V units = 230V
USA> 400V units = 460V
200V units = 230V
BF, MC
5.10 Motor rated power factor 0 ~ 1.00 RW Uni 0.85 BS, MC
5.11 No of motor poles 0 ~ 4 RW Uni Txt (Auto)0 BS, MC
5.12 Autotune 0 ~ 2 RW Uni 0 B
5.13 Variable V to F select 0 or 1 RW Bit 0 BS, MC
5.14 Voltage mode selector 0 ~ 3 RW Uni 3 BS, MC
5.15 Low frequency voltage boost
0 ~ 25.0% of
[5.09]
RW Uni 3.0 BF, MC
5.16 Not used
5.17 Stator resistance 0 ~ 99.99Ω RW Uni 0.0 BS, MC
5.18 PWM switching frequency selector
3,6,12 kHz
(0 ~ 2)
RW Uni
Size 1 to 4: (1)6kHz
Size 5: (0)3kHz
B
5.19
High stability space vector
modulation select
0 or 1 RW Bit 0 B
5.20~
5.22
Not used
5.23 Voltage offset 0 ~ 25.5V RW Uni BF, MC
5.24 Motor leakage inductance 000.0 ~ 500.0mH RO Uni P A
5.25~
5.33
Not used
5.34 Speed indication selector 0 ~ 2 RW Uni Txt P 0(Fr) B
