Control Techniques COMMANDER SE User Manual

Commander SE Advanced User Guide 41
Issue Number: 4
Post-ramp
reference
2.01
P gain
4.13
I gain
4.14
Torque mode selector
4.11
Current demand
4.04
%
Pre-ramp
reference
1.03
Menu 2 Ramp control
Current limit active
10.09
Motor frequency
5.01
Motor
0 1
01
1 0
Current
limit
4.07
Overload detection 4.15
Motor thermal
time constant
4.16
Motor
protection mode
Current measurement
4.01
Magnitude
4.17
Magnetising
Active
4.02
Load 4.20 Overload accumulator
4.19
Alarm
10.17
4.18
Over-riding
current
limit
%
5.01
Motor frequency
Torque to current conversion
Torque reference
4.08
Rated frequency
5.06
*21.06
M
Menu 5 Motor map
* Indicates parameter from second motor map
Menu 1
MENU 4
Current control
