Control Techniques COMMANDER SE User Manual

Commander SE Advanced User Guide 51
Issue Number: 4
3.6 Menu 6: Drive sequencer
Parameter Range Type Default Setting
Update
Rate
6.01 Stop mode selector 0~4 RW Uni 1 L1
6.02 Not used
6.03 AC supply loss mode selector 0~2 RW Uni 0 L2
6.04 Start/stop logic select 0 ~ 4 RW Uni R 0 B, I
6.05 Not used
6.06 Injection braking level
0 ~ Active
current limit
RW Uni 100 B
6.07 Injection braking time 0.0 ~ 25.0 secs RW Uni 1.0 L1
6.08 Not used
6.09 Synchronize to a spinning motor 0 ~ 3 RW Uni 0 B
6.10~
6.11
Not used
6.12 Keypad stop key enable 0 or 1 RW Bit
(EUR) 0
(USA) 1
B
6.13 Keypad fwd/rev key enable 0 or 1 RW Bit 0 L1
6.14 Not used
6.15 Drive enable 0 or 1 RW Bit 1 L1
6.16 Electricity cost/kWh 0.0 ~ 600.0 RW Uni 0 B
6.17 Power consumption meter reset 0 or 1 RW Bit 0 B
6.18~
6.21
Not used
6.22
Run time log
Years/Days
0 ~ 9.364
Years.Days
RO Uni S P B
6.23
Run time log
Hours/Minutes
0 ~ 23.59
Hours.Minutes
RO Uni S P B
6.24 Power meter MWh 0.0 ~ 999.9 Mwh RO Uni S P B
6.25 Power meter kWh 0.0 ~ 99.99 kWh RO Uni S P B
6.26 Running cost
0 ~ 32000
Currency/Hour
RO Uni P B
6.27~
6.28
Not used
6.29 Hardware enable 0 or 1 RW Bit 0 L1
6.30 Digital input control bit 0 (Run/Fwd) 0 or 1 RW Bit 0 L1
6.31 Digital input control bit 1 (Jog) 0 or 1 RW Bit 0 L1
6.32 Digital input control bit 2 (Run/Rev) 0 or 1 RW Bit 0 L1
6.33 Digital input control bit 3 (Fwd/Rev) 0 or 1 RW Bit 0 L1
6.34 Digital input control bit 4 (Run) 0 or 1 RW Bit 0 L1
6.35~
6.38
Not used
6.39 Digital input control bit 5 (Not Stop) 0 or 1 RW Bit 0 L1
6.40 Enable latching run inputs 0 or 1 RW Bit 0 L1
6.41 Control word mask RW Uni 0 L1
6.42 Control word RW Uni 0 L1
6.43 Control word enable 0 or 1 RW Bit 0 L1
