18 Commander SE Advanced User Guide
Issue Number: 4
3.1 Menu 1: Speed reference selection, limits and filters
* The maximum value is 1.06 or 21.01.
Parameter Range Type Default Setting
Update
Rate
1.01 Level of reference selected ±1000.0 Hz* RO Bi P L2
1.02 Pre-filter reference ±Max RO Bi P L2
1.03 Pre-ramp reference ±Max RO Bi P L2
1.04 Not used
1.05 Jog reference 0 ~ 400.0Hz RW Uni 1.5 L2
1.06 Maximum speed clamp 0 ~1000.0Hz RW Uni
50(EUR)
60(USA)
B
1.07 Minimum speed clamp 0 ~ [1.06] RW Uni 0.0 B
1.08~
1.09
Not used
1.10 Allow negative digital references 0 or 1 RW Bit 0 B
1.11 Reference enabled indicator 0 or 1 RO Bit P L1
1.12 Reverse selected indicator 0 or 1 RO Bit P L1
1.13 Jog selected indicator 0 or 1 RO Bit P L1
1.14 Reference selector 0-5 RW Uni Txt
0(EUR)
4(USA)
L2
1.15 Preset selector 0-8 RW Uni 0 L2
1.16 Not used
1.17 Keypad reference ±Max RO Bi S P 0.0 B
1.18 Precision reference ±1000.0Hz RW Bi 0.0 L2
1.19 Precision reference trim 0 ~ 99mHz RW Uni 0 L2
1.20 Precision reference update disable 0 or 1 RW Bit 0 L2
1.21 Preset speed reference 1 ±1000.0Hz RW Bi 0.0 L2
1.22 Preset speed reference 2 ±1000.0Hz RW Bi 0.0 L2
1.23 Preset speed reference 3 ±1000.0Hz RW Bi 0.0 L2
1.24 Preset speed reference 4 ±1000.0Hz RW Bi 0.0 L2
1.25 Preset speed reference 5 ±1000.0Hz RW Bi 0.0 L2
1.26 Preset speed reference 6 ±1000.0Hz RW Bi 0.0 L2
1.27 Preset speed reference 7 ±1000.0Hz RW Bi 0.0 L2
1.28 Preset speed reference 8 ±1000.0Hz RW Bi 0.0 L2
1.29 Skip frequency 1 0 ~1000.0Hz RW Uni 0.0 B
1.30 Skip frequency band 1 0 ~ 5.0Hz RW Uni 0.5 B
1.31 Skip frequency 2 0 ~1000.0Hz RW Uni 0.0 B
1.32 Skip frequency band 2 0 ~ 5.0Hz RW Uni 0.5 B
1.33 Skip frequency 3 0 ~1000.0Hz RW Uni 0.0 B
1.34 Skip frequency band 3 0 ~ 5.0Hz RW Uni 0.5 B
1.35 Reference in skip frequency band indicator 0 or 1 RO Bit P L2
1.36 Analog reference 1 ±1000Hz* RO Bi L2
1.37 Analog reference 2 ±1000Hz* RO Bi L2
1.38~
1.40
Not used
1.41 Analog reference 2 select 0 or 1 RO Bit L2
1.42 Preset reference select 0 or 1 RO Bit L2
1.43 Keypad reference select 0 or 1 RO Bit L2
1.44 Precision reference select 0 or 1 RO Bit L2
1.45 Preset select bit 0 0 or 1 RO Bit L2
1.46 Preset select bit 1 0 or 1 RO Bit L2
1.47 Preset select bit 2 0 or 1 RO Bit L2
1.48 Not used
1.49 Reference selected indicator 1 ~ 5 RO Uni P L2
1.50 Preset selected indicator 1 ~ 8 RO Uni P L2
1.51 Power up keypad reference 0 ~ 2 RW Uni Txt 0 I
