3.7 Menu 7: Analog inputs and outputs
Parameter Range Type Default Setting
Update
Rate
7.01 Analog input 1 (Terminal 2) 0 ~ 100.0% RO Uni P L2
7.02 Analog input 2 (Terminal 5) 0 ~ 100.0% RO Uni P L2
7.03 Not used
7.04 Heatsink temperature 0 ~ 100°CROUni P B
7.05~
7.07
Not used
7.08 Analog input 1 scaling 0.00 ~ 2.50 RW Uni 1.0 B, I
7.09 Analog input 1 invert bit 0 or 1 RW Bit 0 L2
7.10 Analog input 1 destination parameter
0.00 ~ 21.51
Menu.parameter
RW Uni R P P1.36 I
7.11 Analog input 2 mode selector
(0)0 ~ 20
(1)20 ~ 0
(2)4 ~ 20
(3)20 ~ 4
(4)4 ~ .20
(5)20 ~ .4
RW Uni Txt (4)4-.20 L2
7.12 Analog input 2 scaling 0.00 ~ 2.50 RW Uni 1.0 B, I
7.13 Analog input 2 invert bit 0 or 1 RW Bit 0 L2
7.14 Analog input 2 destination parameter
0.00 ~ 21.51
Menu.parameter
RW Uni R P P1.37 I
7.15~
7.18
Not used
7.19
Analog output source selector
(Terminal 6)
0.00 ~ 21.51
Menu.parameter
RW Uni P
2.01-Post ramp
reference
B, I
7.20 Analog output scaling 0.00 ~ 2.50 RW Uni 1.0 L3
7.21~
7.27
Not used
7.28 Current loop loss indicator 0 or 1 RO Bit P L2
7.29~
7.32
Not used
7.33 Analog output select
(0)Fr
(1)Ld
(2)Adv
RW Uni Txt R (0)Fr B
