Commander SE Advanced User Guide 33
Issue Number: 4
3.3 Menu 3: Speed sensing thresholds
If the post-ramp frequency reference (2.01) is at or below the setting of this parameter in either direction, the 'zero speed'
indicator (10.03) is set to 1, otherwise the indicator is set to 0.
The 'At speed' window threshold defines the boundary around the set speed point in which the 'At speed' indication (10.06) is
set to 1.
The 'At speed' window is defined as Set speed ± (3.06/2).
Parameter Range Type Default Setting Update Rate
3.01~
3.04
Not used
3.05 Zero-speed threshold 0.0 ~ 20.0Hz RW Uni 1.0 B
3.06 At speed window threshold 0.0 ~ 20.0Hz RW Uni 1.0 B
3.01 ~
3.04
Unused parameters
3.05 Zero-speed threshold
Ú
0.0 ~ 20.0
Ö
1.0 Hz RW Uni
3.06 At speed window threshold
Ú
0.0 ~ 20.0
Ö
1.0 Hz RW Uni
