154 Commander SE Advanced User Guide
Issue Number: 4
Further data for the filters is given in the following tables:
Table 11-10 Commander SE Size 1
Table 11-11 Commander SE Size 2
Table 11-12 Commander SE Size 3
*Also used on Size 2 units.
Table 11-13 Commander SE Size 4
Table 11-14 Commander SE Size 5
Discharge resistors
1.5MΩ in a star connection between phases with star point connected by a 680kΩ resistor to ground.
This may cause an earth leakage indication in monitored ungrounded power systems such as IT systems.
For tables 11-9 to 13-14, please be aware of the following:
Weight is unpacked weight.
Worst case leakage current:
Single phase filters - when the neutral is disconnected.
Three phase filters - when an input phase is disconnected.
The data is given for an input voltage of 230V, 50Hz.
Part
Number
Maximum
Power
Losses
IP Rating Weight
Operational
Leakage
Current
Worst Case
Leakage
Current
Filter Terminal
Tightening Torque
Filter
current
rating
WkglbmAmANmlb ftA
4200-6101 6 21 0.49 1.1 4.0 8.0 0.8 0.6 12
4200-6102 6 20 0.60 1.3 40.7 77.5 0.8 0.6 12
4200-6103 6 21 0.60 1.3 2.9 5.7 0.8 0.6 12
Part
Number
Maximum
Power
Losses
IP Rating Weight
Operational
Leakage
Current
Worst Case
Leakage
Current
Filter Terminal
Tightening Torque
Filter
current
rating
WkglbmAmANmlb ftA
4200-6201 10.1 20 1.2 2.6 89 128 0.8 0.6 26
4200-6202 10.1 20 1.1 2.4 45.7 184.2 0.8 0.6 16
4200-6203 15.4 20 1.3 2.9 26.4 106.3 0.8 0.6 26
4200-6204 6 20 0.7 1.5 29.5 58.9 0.8 0.6 26
4200-6205 10.1 20 1.2 2.6 2.8 5.7 0.8 0.6 26
4200-6207 10.1 20 1.1 2.4 3 18.3 0.8 0.6 16
4200-6209 15.4 20 1.3 2.9 2.6 15.5 0.8 0.6 26
Part
Number
Maximum
Power
Losses
IP Rating Weight
Operational
Leakage
Current
Worst Case
Leakage
Current
Filter Terminal
Tightening Torque
Filter
current
rating
WkglbmAmANmlb ftA
4200-6301 12.4 20 1.6 3.5 45.7 184.2 0.8 0.6 17
4200-6302 19.5 20 1.7 3.7 26.4 106.3 0.8 0.6 30
4200-6303
*
10.8 20 0.8 1.7 14.1 68 0.8 0.6 30
4200-6304
*
6.1 20 0.6 1.3 33 148 0.8 0.6 17
Part
Number
Maximum
Power
Losses
IP Rating Weight
Operational
Leakage
Current
Worst Case
Leakage
Current
Filter Terminal
Tightening Torque
Filter
current
rating
WkglbmAmANmlb ftA
4200-6401 26.1 20 3.1 6.8 29.4 280 2.2 1.6 33
4200-6402 11.7 20 1.1 2.4 14.1 68 2.2 1.6 33
4200-6403 30 20 3.1 6.8 38 220 2.2 1.6 37
4200-6404 16 20 1.2 2.6 24.5 132 2.2 1.6 37
Part
Number
Maximum
Power
Losses
IP
Rating
Weight
Operational
Leakage
Current
Worst Case
Leakage
Current
Terminal
Torques
Ground
Connection
Torque
Filter
current
rating
W kg lb mA mA Nm lb ft Nm lb ft A
4200-6116 12.8 20 3.8 9 31 143 4.5 3.3 2.2 1.6 50
4200-6117 14.3 20 3.8 9 29 126 4.5 3.3 4.0 2.9 63
4200-6106 25.5 20 7.8 17 48.5 209 8.0 5.9 9.0 6.6 100
NOTE
NOTE
