188 Commander SE Advanced User Guide
Issue Number: 4
Example 2
This set up uses the UP and DOWN buttons on the Universal Keypad to control the speed of the motor: UP to increase the
speed and DOWN to decrease the speed.
The Stop/Start/Forward/Reverse control is from the Universal Keypad Stop/Start/Forward/Reverse buttons and not the drive’s
terminals.
Keypad top line display set up
Keypad bottom line display set up
Keypad buttons set up
Drive parameters set up
Perform a drive save routine: xx.00 = 1000 and press the Stop / Reset button on the drive.
Perform a Universal Keypad save routine: 99.00 = 1000 and press the red Stop / Reset button on the keypad.
Example 3
This set up uses the drive’s motor potentiometer function with the Universal Keypads F1 button used to increase the motor
speed and F3 button to decrease the motor speed. The Stop/Start/Forward/Reverse control is from the drive’s terminals.
The macro buttons F1 and F3 are latching so they need to be pressed twice to clear i.e. pressing F1 starts the
increase in speed, a second press of F1 stops the increase in speed.
Keypad top line display set up
Keypad bottom line display set up
Parameter Description Value
99.16 HMI 2 source address 11
99.17 HMI 2 source parameter 1.21
99.20 HMI 2 text Speed reference
99.41 HMI 2 increment 100
99.42 HMI 2 upper limit 50,000
99.43 HMI 2 lower limit 0
Parameter Description Value
99.09 HMI 1 source address 11
99.10 HMI 1 source parameter 4.01
99.13 HMI 1 text Motor I
99.05 Control Keys Enable
Parameter Description Value
99.05 Keypad control buttons Enable
Parameter Description Value
00.05 Speed reference selector Pr
6.41 Control word mask 11
6.43 Control word enable 1
Parameter Description Value
99.16 HMI 2 source address 11
99.17 HMI 2 source parameter 1.21
99.20 HMI 2 text Speed reference
99.41 HMI 2 increment 100
99.42 HMI 2 upper limit 50,000
99.43 HMI 2 lower limit 0
Parameter Description Value
99.09 HMI 1 source address 11
99.10 HMI 1 source parameter 4.01
99.13 HMI 1 text Motor I
NOTE
