Commander SE Advanced User Guide 189
Issue Number: 4
Keypad buttons set up
Drive parameters set up
Perform a drive save routine: xx.00 = 1000 and press the Stop / Reset button on the drive.
Perform a Universal Keypad save routine: 99.00 = 1000 and press the red Stop / Reset button on the keypad.
Example 4
If it is required that control is from the Universal keypad’s Stop/Start/Forward/Reverse buttons rather than the drive’s
terminals, program the following parameters in addition to those already programmed using Example 3.
Keypad buttons set up
Drive parameters set up
Perform a drive save routine: xx.00 = 1000 and press the Stop / Reset button on the drive.
Perform a Universal Keypad save routine: 99.00 = 1000 and press the red Stop / Reset button on the keypad.
Parameter Description Value
99.23 F1 button assignment 2 Values
99.25 F1 button destination 815
99.26 F1 button destination value 1 1
99.27 F1 button destination value 2 0
99.33 F3 button assignment 2 Values
99.35 F3 button destination 816
99.36 F3 button destination value 1 1
99.37 F3 button destination value 2 0
Parameter Description Value
7.10 Analog input 1 destination 0
8.21 Digital input / output destination / source 9.28
8.25 Digital input 5 destination 9.26
8.26 Digital input 6 destination 9.27
8.39 Disable auto set up 1
9.04 If drive is not running, potentiometer is held at zero 10.02
9.08 Invert output 1
9.10 Motorised potentiometer reset 09.28
9.21 Zero start select 1
9.23 Rate of increase / decrease 20
9.25 Motorised potentiometer destination 1.36
Parameter Description Value
99.05 Keypad control buttons Enable
Parameter Description Value
6.41 Control word mask 11
6.43 Control word enable 1
