88 Commander SE Advanced User Guide
Issue Number: 4
If this parameter is set to a non-zero value and the drive reset the selected default parameters will automatically be loaded.
0no do nothing
1Eur Load European 50Hz defaults
2USA Load USA 60Hz defaults
3br.Eu Load European 50Hz Defaults With Brake Function
4br.USLoad USA 60Hz Default With Brake Function
This read write parameter defines the level of security for menu 0
0L1 Only the first ten parameters can be accessed
1L2 All parameters in level 1 and level 2 can be accessed
2 Loc Lock security, so that the security code must be entered before a parameter can be edited and set security
status to L1. For this to be acted upon a Drive Reset must be performed.
When this bit is set to 1 the Motor two parameter set becomes active. The following parameter changes are made:
Changes will only be implemented when the drive is in a disabled state. When the second motor parameter set is active, the
decimal point in the centre of the two digit display will be illuminated and 21.15 will change from logic 0 to 1.
11.43 Load default parameters
Ú
0 ~ 4
Ö
0 RW Uni Txt R
11.44 Security status
Ú
0 ~ 2
Ö
0 RW Uni Txt R
11.45 Select motor 2 parameters
Ú
0 or 1
Ö
0 RW Bit
Motor 1 Motor 2
Maximum Speed 1.06 21.01
Minimum Speed 1.07 21.02
Reference Select 1.14 21.03
Acceleration rate 2.11 21.04
Deceleration Rate 2.21 21.05
Rated Frequency 5.06 21.06
Rated Current 5.07 21.07
Rated RPM 5.08 21.08
Rated Voltage 5.09 21.09
Rated PF 5.10 21.10
No of Poles 5.11 21.11
Stator resistance 5.17 21.12
Voltage Offset 5.23 21.13
Machine Inductance 5.24 21.14
Motor Map 2 Active - 21.25
