2.11.4 THE LIQUID DATA MENU
This menu shows the current Liquid Data parameters.
Temp1 Current liquid temperature.
Temp 2 Current liquid temperature.
Reynolds # Current Reynolds number.
LiquIdent The LiquIdent™ Index is the sonic velocity of the liquid at 60ºF(15.6ºC).
Pressure Measured pressure.
Viscosity (cS) Kinematic viscosity of a liquid measured in centistokes.
LIQUID DATA MENU ITEMS
Temp1 78.5
Temp 2 40.1
Reynolds # N/A
LiquIdent 1292.80 m/s
Pressure 14.5 PSIA
Viscosity (cS) 1.000 cS
Controlotron Dual Path SITE 1
RTD 1 temperature sensor reading
Liquid Data
TN uSec The total elapsed time between the transmission and reception of a sonic
pulse.
TL uSec The total time a sonic pulse takes to travel through the liquid.
DeltaT nSec This is the instantaneous result of subtracting the down from the up tran-
sit times.
Note: This will appear to be more active than dampened flow
readings.
Burst/Sec Number of transmissions per second under current operating conditions.
The following factors influence this parameter: aeration, pressure trans-
ients, signal strength variation.
% Accepted The running tally of accepted and rejected up/down burst sets.
Last Makeup Reason for last Makeup (signal reacquisition).
Makeup Status Current stage of Makeup routine. [Measurement = normal operation]
