1-8
1010PVNFM-3A
Section 1
As shown in the steps below, selecting this mode only requires <Right Arrow> presses. This is
because dual-channel clamp-on is the default configuration for this instrument. To select a
different configuration, move the cursor to the desired Meter Type and then press <ENT> to
select it.
1. Make sure that the keypad enable switch is in the [Enable-Up] position. Turn on power and
press <MENU> to access the [Meter Type] screen. Refer to the figure below.
Note that on the left-hand column, [Meter Type] is highlighted as is all the available meter
types on the right-hand column. Press the <Right Arrow>. This places a cursor next to
[Dual Path Flow].
Controlotron Dual Path SITE 1
Select Meter Type
Meter Type >Dual Channel Flow
Meter Facilities
Creating a New Site Setup (See paragraph 2.1.1)
The Channel/Path Setup section of this manual provides detailed instructions on how to use
all the Channel/Path Setup menu commands. This section provides an example of how to use
the [Create/Rename Site] command to create a new site setup. Always begin a new installa-
tion by issuing the [Create/Name Site] command. Although you do not need to enter a site
name to create a new site setup, you have to provide one to save the site setup or to identify
the source of logged data. In this example, we will use [SITE1] for the site name.
1. To access the [Channel/Path Setup] menu, press the <Right Arrow> then move the high-
light down to [Create/Name Site].
2. Press the <Right Arrow> again. This selects [Dual Path Flow]. Pressing <ENT> will also
access the [Dual Path Flow] menu.
Channel/Path Setup
Pipe Data
Application Data
Pick/Install Xdcr
Operation Adjust
Flow/Total Units
Data Span/Set/Cal
Stripchart Setup
Datalogger Setup
I/O Data Control
Diagnostic Data
Controlotron Dual Path SITE 1
Dual Path Flow
Conforms operation to user Preferences
