4.2 THE TABLE SETUPS MENU
The [Table Setups] menu allows you to pre-condition your pipe table and transducer types.
The edits made in [Table Setups] become the default settings for creating a new site. Trans-
ducers “marked” in the [Transducer Types] menu will be preferentially selected when the
meter recommends transducers during the automatic Pick/Install Transducer routine.
To access the Table Setups menu press
4.2.1 PIPE TABLE
The factory-programmed pipe table describes over sixty standard English and metric pipes.
The table can save you programming steps by loading all required data at once from option
list selection. The Pipe Table configuration is [PIPE CLASS è PIPE NAME]. Pipe Class pre-
sents a list of standard metric and English Pipe classifications. Selecting a class (e.g.,
ASA Carbon Steel) conditions the Pipe Name option list to all the stored pipes within that
class (see Menu Chart above). Selecting a pipe by its name (e.g., 2SS10) loads a description
of that pipe in the remaining menu cells. Note that liner data is not provided. If your pipe is
lined, then you will be required to enter the liner material and its thickness manually.
To access the Pipe Table menu press
*NOTE: The highlighted selection in the above table illustrates how to choose the ASA Stainless Steel Pipe
Class and all its available Pipe Name selections. All other Pipe Classes (e.g., ASA Carbon Steel)
listed can be selected in the same manner.
(continued)
Create/Edit Pipe Choose Pipe Class ASA Stainless Steel*
ASA Carbon Steel
ASA Plastic
Metric DN Steel
Metric SGP Steel
Cast Iron Table
Ductile Iron Table
Copper Tube Table
Choose Pipe Name ASA Stainless Steel* ASA Carbon Steel ASA Plastic
1SS10 1CS40 1P40
2SS10 1CS80 1P80
3SS10 2CS40 2P40
4SS10 2CS80 2P80
6SS10 3CS40 3P40
8SS10 3CS80 3P80
Metric DN Steel 4CS40 4P40
50DN 4CS80 4P80
ô
ô
ô
ð
ð
ô
ô
ô
ô
ð
ð
PIPE TABLE MENU STRUCTURE
ð
ô
Table Setups Pipe Table
Transducer Type
