Controlotron 1010PVN - The Clamp-On Menu

5-14
1010PVNFM-3A
Section 5
Meter Facilities Clock Set Date
Time
RS-232 Setup Baud Rate
Parity
Data Bits
Line Feed
Network ID
RTS Key Time
Backlight 30 sec, 1 min, 2 min, 3 min, 5 min, 10 min
System Info Version
Reset Date/Time
Op System P/N
Checksum
Code
METER FACILITIES MENU (continued)
ð
ô
ð
ð
ð
ô
ð
ô
ô
ð
ð
ð
ð
ô
ô
ô
(continued)
THE CLAMP-ON MENU
Clamp-On Chan/Path Setup Recall Site Setup
Channel Enable
Create/Name Site
Site Security
Delete Site Setup
Save/Rename Site
Pipe Data Select Pipe Class
Select Pipe Size
Pipe OD (in / mm)
Pipe Material
Wall Thickness
Liner Material
Liner Thickness
ThermExp Coef 1/F
Mod of Elast PSIA
Application Data Liquid Class Select Liquid
Estimated Vs m/s
Viscosity (cS)
Density S.G.
LiquidTable Table Active
LiquIdent Slope
Pressure Slope
Base Temperature
LiquIdent Index
Temperature Range -40 to 250F
-40 to 375F
-40 to 450F
Pipe Configuration Fully Developed
1 Elbow
Dbl Elbow +
Dbl Elbow -
Valve
Expander
Reducer
Norm Entry
Header Inlet
Intrusions
Anomaly Diams 10
Pick/Install Xdcr Install Path
Transducer Model
Transducer Size
ð
ô
ô
ô
ô
ð
ô
ô
ô
ô
ð
ð
ð
ð
ð
ð
ð
ô
ð
ð
ð
ð
ô
ð
ô
ô
ô
ô
ô
ð
ô
