Controlotron 1010PVN - The Empty Pipe Set Menu; How to Use the Actual MTY Command; How to Use the Mtymatic Command

2-29
1010PVNFM-3A
Section 2
If you want to redo the Initial Makeup, move cursor to [New Makeup], then press <ENT>.
This resets the option list. You can now repeat the install routine described previously.
2.4.9 THE EMPTY PIPE SET MENU
The flow computer performs the MTYmatic routine automatically during its Initial Make-
up to establish a standard setting for the Empty Pipe alarm. The [Empty Pipe Set] option
list allows you to re-invoke MTYmatic, use an Actual MTY routine (if application condi-
tions allow you to empty and refill the pipe) or use the Set Empty routine to set the empty
pipe threshold by direct numeric entry.
How to Use the Actual MTY Command
If application conditions allow you to empty and refill the pipe, then you should perform the
Actual Empty procedure. This is the recommended way to define the empty pipe threshold.
NOTE:
NEVER perform this procedure when the pipe is full.
To perform the Actual MTY Procedure:
To access the [Empty Pipe Set] option list press
To move the cursor to [Actual MTY] press then
Empty the pipe completely, then press . appears on the
Refill the pipe completely, then press
How to Use the MTYmatic Command
You can repeat MTYmatic (performed during the Initial Makeup) to correct an inaccurate
Actual MTY setting if conditions do not allow you to repeat the Actual Empty procedure.
NOTE: Only use the MTYmatic procedure when the pipe is full.
To start MTYmatic:
To access the [Empty Pipe Set] option list press
Move the cursor next to [MTYmatic] by pressing
To invoke MTYmatic press
After the flow computer completes its Initial Makeup command, the [Install Completed?]
option list changes to:
appears on the menu prompt line.
menu prompt line.
ENT
ENT
ENT
ENT
Install Completed? Yes
New Makeup
[Empty Pipe Press Enter]
[Fill Pipe Press Enter]
