Controlotron 1010PVN - Manual Adjustment Procedure; Automatic Adjustment Procedure

2-73
1010PVNFM-3A
Section 2
“Manual” Adjustment Procedure
l In the [Site Setup Data] Menu, press the <Down Arrow> and scroll to the [HF] menu
cell. Press the <Right Arrow> and a pop-up [Manual] prompt will appear as shown
below. Note: Press the <Up/Down Arrow> to select [Automatic], if desired.
l Use the numerical keys to input the desired correction value. Press <ENT> to input
value.
l In the [Diagnostic Data] Menu, highlight [Path Select] and select the desired transducer
path. Press <ENT> to select path.
l Press the <Down Arrow> and scroll to the [Site Setup Data] menu cell. Press the <Right
Arrow> to select it.
l The new correction value will appear next to the [HF] menu cell as shown below.
“Automatic” Adjustment Procedure
l In the [Site Setup Data] Menu, press the <Down Arrow> and scroll to the [HF] menu
cell. Press the <Right Arrow> and a pop-up [Manual] prompt will appear.
l Press the <Up or Down Arrow> to select [Automatic] then press <ENT>.
fx (drive) 29
N (burst length) 5
Ltn in 5.316
Vf max CU
>Manual
Vs max m/s = -0.120
Vs min m/s 1355.00
Empty %
Samples/Cycle 29
HF >-0.000
Controlotron Dual Path 4SS10G
Site Setup Data
fx (drive) 29
N (burst length) 5
Ltn in 5.316
Vf max CU
Adjustment
Vs max m/s >Manual
Vs min m/s 1355.00
Empty %
Samples/Cycle 29
HF >-0.000
Controlotron Dual Path 4SS10G
Site Setup Data
fx (drive) 29
N (burst length) 5
Ltn in 5.316
Vf max CU
Vs max m/s
Vs min m/s 1355.00
Empty %
Samples/Cycle 29
HF >-0.120
Controlotron Dual Path 4SS10G
Site Setup Data
