Assigning Pgen Output Functions
The Pgen analog output is a buffered TTL compliant pulse rate signal whose configuration is
detailed in Installation Drawing 1010N-2-7. It varies linearly from 0-5000 Hz in relation to a
selected data function.
NOTE: The analog Pgen function is not available in Custody Transfer flowmeters. See
paragraph 2.7.1 for details.
To assign a function to the Pgen output:
To access the [Pgen] option list press
Move the cursor to the desired data function by pressing
To store selection press
NOTE: If you have an Expanded I/O Module 1010N-7, refer to addendum 1010FMA-14
in this manual.
Assigning Io Output Functions
The Io analog output is a self-powered, isolated 4-20mADC signal that varies linearly in rela-
tion to a selected data function.
CAUTION: Do not connect to a powered loop.
To assign a function for the current output:
From Analog Out Setup, press twice to access the [Io] option list.
Move the cursor to the desired data function by pressing
To store selection press
Assigning Vo Output Functions
The Vo analog output is a 0-10 VDC signal that varies linearly in relation to a selected func-
tion. The output is mirrored in correct for flowmeter equipped with a 1010N-7 enhanced I/O
module.
To assign a function to the voltage output:
To access the [Vo] option list press
Move the cursor to the desired data function by pressing
To store selection press
ENT
ENT
PULSE OUTPUT (Pgen Wiring)
1010PVN & 1010PVDN with 1010N-2 Modules
Installation Drawing 1010N-2-7 (Sheet 2 of 2)
PIN# SIGNAL FUNCTION NOTES
11 PGEN 1+ FREQUENCY OUTPUT 1 0 - 5000 Hz, 5 Volt Logic, Square Waveform
12 PGEN 1- REF. GROUND
13 PGEN 2+ FREQUENCY OUTPUT 2
14 PGEN 2- REF. GROUND
TB2
To Next Page
