Controlotron 1010PVN - Diagnostics Data Menu Structure

2-66
1010PVNFM-3A
Section 2
Diagnostic Data Path Select 1 and 2
1
2
Path Enable N/A
Flow Data Flow (Units)
Flow Vel F/S
Total (Units)
Vs m/s
Signal mV
Valc %
Vaer %
Alarm Status
Ancal (Units)
HiFlow (Units)
LoFlow (Units)
Application Info TN uSec
TL uSec
DeltaT nSec
Burst/Sec
% Accepted
Last Makeup
Makeup Status
Liquid Data Temp 1
Temp 2
Reynolds #
LiquIdent
Pressure
Viscosity (cS)
Site Setup Data fx (drive)
N (burst length
Ltn in
Vfmax
Vs max m/s
Vs min m/s
Empty %
Samples/Cycle
HF
Test Facilities Makeup
Graph
Tx Up
Tx Dn
Fixed ALC
Tx Up Fixed ALC
Tx Dn Fixed ALC
Graph AutoZero
Print Site Setup No
Yes
Date Site Created xx.xx.xx xx.xx.xx
DIAGNOSTIC DATA MENU STRUCTURE
ô
ô
ô
ô
ô
ô
ð
ð
ð
ð
ð
ð
ð
ð
ð
ô
ô
ô
ô
ô
ô
ô
ð
ô
NOTE: Diagnostic Data menus on [Dual Path Flow] meter setups include [Path Se-
lect] and [Path Enable]. Ch 1+2 Flow and Ch 1-2 Flow virtual Channel 3 menus
only include [Flow Data], [Print Setup] and [Data Site Created].
