4-4
1010PVNFM-3A
Section 4
Scroll the option list to a class that provides the closest match to your pipe
To select the [Pipe Class] press . This moves the highlight to [Choose Pipe Name].
To access the [Pipe Name] option list press .
Scroll the option list to a pipe name and press to select it.
This loads Outer Diameter and Wall Thickness for the selected pipe.
The highlight moves to [Outer Diameter]. Press to enable numeric entry. Type
the actual pipe OD using the appropriate English or metric units. Press to store
the OD. The highlight moves to [Wall Thickness].
Press to enable numeric entry. Type the actual wall thickness using the
appropriate English or metric units. Press to store the wall thickness.
Select a Liner Material and enter its thickness (if required).
Press to leave the Create/Edit Pipe menu. This triggers the Save Pipe pop-
up Window. Note that the second line lists the name of the selected pipe. Press
and then press to use this name.
To use a new name, press and then use the appropriate arrow keys to rename
the pipe (8 chars. Max.). Press . This adds the new pipe to the pipe class.
4.2.3 DELETE PIPE
This menu allows you to remove any of the pre-loaded pipes within a class from a pipe table.
We recommend that you use this function only to delete pipes that you have added so as to
preserve the factory presets.
To delete a pipe from the Pipe Table:
To access the [Delete Pipe] menu press . To access the [Pipe Class] option list
Scroll the option list to the class that contains the pipe to be deleted.
To select [Pipe Class] press . This moves the highlight to [Choose Pipe Name].
To access the [Pipe Name] option list press .
Scroll the option list to the pipe to be deleted by pressing .
To remove it from the pipe table press .
4.3 TRANSDUCER TYPE MENU
During the Transducer Install procedure, System 1010 analyzes the entered pipe and liquid
data, then automatically generates a list of the transducer sizes most suited for the applica-
ENT
ENT
ENT
ENT
ENT
ENT
ENT
ENT
