Controlotron 1010PVN - 2.7 THE DATA SPAN;SET;CAL MENU

2-43
1010PVNFM-3A
Section 2
Controlotron Dual Path SITE1
Define data Alarm thresholds
Data Span/Set/Cal
Span Data
Set Alarm Levels
Calibrate Flowrate Intrinsic
Calib. Table 1
Calib. Table 2
Calib. Table 3
Use this menu to define
setpoints for the alarm
relay outputs.
Use this menu to set the
low and high range for
analog outputs.
Use this menu cell to
enter a calibration
slope factor for
volumetric flow (Vfo).
Use these menu cells to
enter Index Variables and
their Set Points, activate
and clear tables.
Data Span/Set/Cal Span Data PGEN P/(Units)* xxxx.xxx (numeric entry)
Max Flow (Units) x.xxx (numeric entry)
Min Flow (Units) x.xxx (numeric entry)
Max Liquident x.xxx (numeric entry)
Min Liquident x.xxx (numeric entry)
Max Vs m/s x.xxx (numeric entry)
Min Vs m/s x.xxx (numeric entry)
Max Viscosity cS x.xxx (numeric entry)
Min Viscosity cS x.xxx (numeric entry)
Max Temperature x.xxx (numeric entry)
Min Temperature x.xxx (numeric entry)
Set Alarm Levels High Flow x.xxx (numeric entry)
Low Flow x.xxx (numeric entry)
High Liquident x.xxx (numeric entry)
Low Liquident x.xxx (numeric entry)
High Viscosity cS x.xxx (numeric entry)
Low Viscosity cS x.xxx (numeric entry)
High Temperature x.xxx (numeric entry)
Low Temperature x.xxx (numeric entry)
Interface Vs m/s x.xxx (numeric entry)
Aeration % x.xxx (numeric entry)
Makeup Latch OFF
ON
Calibrate Flowrate Intrinsic
Kc x.xxx (numeric entry)
ð
ô
ð
THE DATA SPAN/SET/CAL MENU STRUCTURE
(continued)
ð
ô
ô
ô
ô
ô
ô
ð
ð
*Present in Custody Transfer flowmeters only.
