CPS SCA50KTL-DO/US-480 - Other Parameters Setting

97
Figure 4-22 Other Parameters Setting
Table 4-10 Other Parameters
Other Parameters
IEEE1547
Rule21
Parameter name
Description
Setting Range
(Min, Default, Max)
Setting Range
(Min, Default, Max)
PowerOnDelay (s)
Startup delay time
{0, 5, 1200}
{0, 5, 1200}
PVSlow StartSlope
(%/P)
The output power will
slowly increase due
to the change of PV
illumination at the
Rule21 standard
{0.01%, 10.00%,
10}
{0.01%, 10.00%,
10}
ErrSoftStartP (%/P)
Power startup step
after Grid Fault
{0.01%, 0.16%,
10%}
{0.01%, 0.16%, 10%}
NormSoftStopP (%/P)
Normal power step in
soft stop
{0.01%, 6.00%, 10%}
{0.01%, 2.00%, 10%}
NormSoftStartP (%/P)
Normal power step in
soft startup
{0.01%, 4.00%, 10%}
{0.01%, 2.00%, 10%}
NormalDeratingStep
Power step in
Derarting
{0.01%, 6.00%, 10%}
{0.01%, 5.00%, 10%}
FaultPowerT
The trigger
temperature of
module (C)
(95.0, 95.0, 95.0)
(95.0, 95.0, 95.0)
FaultEnvT
The trigger
temperature of
enviroment (C)
(83, 83, 83)
(83, 83, 83)
GFCIStaticValue (mA)
The static threshold
value of Leakage
current
(100, 250, 1000)
(100, 250, 1000)
GFCIStaticT (s)
The static threshold
value of Leakage
current
(0, 0.2, 655)
(0, 0.2, 655)
GFCIDynProFactor
The dynamic trigger
coefficient of
Leakage current
(0.0%, 100%, 200%)
(0.0%, 100%, 200%)
DCIProtection1
Maximum DCI
value1
(0.01%, 0.50%,
5.00%)
(0.01%, 0.50%,
5.00%)
DCIProtectionT1 (s)
Trip time 1 of DCI
(0.00, 10.00, 120.00)
(0.00, 10.00, 120.00)
DCIProtection2 (mA)
Maximum DCI
value2
(5, 950, 5000)
(5, 950, 5000)
DCIProtectionT2 (s)
Trip time 2 of DCI
(0.00, 1.00, 120.00)
(0.00, 1.00, 120.00)
PVStartVolt(V)
PV start-up voltage
(300, 330, 400)
(300, 330, 400)
