4.4.2.5 Power Derating Setup
“Power Derating Setup” menu is used to set the active power derating
parameters including Active Power Derating, Over frequency derating,
Low frequency derating, High temperature frequency derating, etc.
The parameters are shown in Figure 4-17.
Active Power Derating
Percentage
CtrMode
P3/3
100.0%
0
Power vs Voltage
OvrVolSlop(Pn/s)
OvrVoltTrip
P1/3
OvrVolFilterT(s)
60
0.0%
110.00
%
OvrFrqMax(Hz)
OvrFrqMin(Hz)
P2/3
OvrFrqSlop(Pn/s)
60.0
0.16%
61.4
60.4
OvrFrqRecoveryT(S)
RecovryFrq(Hz)
60
OvrFrqDeratingMode
0
Disable
Power vs Friquency
LVRT/HVRT Setup
Setting
P1/2
System Parameters
Protection Parameters
Power Derating Setup
Reactive Power Derating Setup
ARC Parameters
Control Command
Figure 4-17 Power Derating Setup
