72
4.4 Main Menu
LCD screen displays “default indication interface” when the inverter is in
operation mode. Press ESC in this interface to escape the default interface
and Press ENT to access the main operation interface. The main operation
interface is shown in Figure 4-5.
Figure 4-5 Main Menu on the LCD Screen
The main menu of the LCD screen has 5 menus, “Measurement Data”,
“Setting”, “Power ON/OFF”, “History Record”, and “Device Information”.
The users may select options by moving the curser up/down with and
, and then press the ENT key to confirm the selection. The users can return
to the default indication interface by pressing the ESC key.
