CPS SCA50KTL-DO/US-480 - Installation of the Wiring Box; Secure the Main Enclosure and Wiring Box to the Bracket

28
Figure 3-12 Installation of the Wiring Box
5. Attach the main enclosure and the wiring box to the mounting
bracket with the M6x18 screws (6 pcs). (see Figure 3-13)
Tool required: No.3 Phillips head screwdriver, torque value of
4N.m (35.4in-lbs)
Figure 3-13 Secure the Main Enclosure and Wiring Box to the Bracket
