4.4.4 History Record
Move the cursor to
History Record
in the main menu interface. Press
ENT
to check the history information.There are 3 submenus in the
History
Record
menu:
Current Error
,
Running Record
and
Fault Record
. See
Figure 4-23.
History Record
Running Record
Fault Record
Current Error
Current Error
P1/1
Date Error
2015/10/22 12:20:08 ArcboardErr
2015/10/22 12:20:08
2015/10/22 12:20:08 Fault0040
2015/10/22 12:20:08
2015/10/22 12:20:08
Time
Fault0040
Fault0040
Fault0040
Fault Record
P1/1
Num Date
Error
001 15/10/22 12:20:08
003 15/10/22 12:20:08
002 15/10/22 12:20:08
004
15/10/22 12:20:08
005 15/10/22 12:20:08
Time
Fault0040
Fault0040
Fault0040
Fault0040
ArcboardErr
Action
ON
ON
ON
ON
ON
Running Record
P1/1
Num Date
Event
001 15/10/22 12:20:08
003 15/10/22 12:20:08
002 15/10/22 12:20:08
004 15/10/22 12:20:08
006 15/10/22 12:20:08
005 15/10/22 12:20:08
Fault
Standby
Standby
On-grid
Off-grid
SysStart
Time
Figure 4-23 History Menu and Submenu
4.4.4.1 Current Error
This log will display any faults that are currently affecting the
operation of the inverter.
