10 Technical Data
10.1 Datasheet
Model Name
CPS
SCA50KTL-DO/US-480
CPS
SCA60KTL-DO/US-480
DC Input
Max. PV Power
75kW (30kW per MPPT)
90kW (33kW per MPPT)
Max. DC Input Voltage
1000V
DC
Operating DC Input Voltage
Range
200-950V
DC
Start-up DC Input Voltage /
Power
330V / 80W
Number of MPP Trackers
3
MPPT Voltage Range
480-850V
DC
540-850V
DC
Max.PV Short-Circuit Current
(Isc x 1.25)
204A (68A per MPPT)
Number of DC Inputs
15 inputs, 5 per MPPT
DC Disconnection Type
Load rated DC switch
DC Surge Protection
Type II MOV, 2800V
C
, 20kA I
TM
(8/20μS)
AC Output
Rated AC Output Power
50kW
60kW
Max. AC Apparent Power
55kVA
66kVA
Rated Output Voltage
480V
AC
Output Voltage Range
1
422-528V
AC
Grid Connection Type
3Φ/PE/N (Neutral optional)
Max. AC Output Current
@480V
AC
66.2A
79.4A
Max AC OCPD Rating
110A
125A
Rated Output Frequency
60Hz
Output Frequency Range
1
57-63Hz
Power Factor
>0.99 (±0.8 adjustable)
Current THD
<3%
Max. Fault Current
Contribution (1 Cycle RMS)
64.1A
AC Disconnection Type
Load rated AC switch
AC Surge Protection
Type II MOV, 1240V
C
, 15kA I
TM
(8/20μS)
1) The "Output Voltage Range" and "Output Frequency Range" may differ according to the specific grid standard.
