Figure 6-1 USB port for firmware upgrades
4. Using the password to enter the Setting menu and select Firmware
Update. Choose the firmware to be updated (LCD or DSP) and follow
the promts on the screen. See figure 6-2.
5. When the update is successful repeat the process, if necessary, to
upate the next firmare (DSP or LCD). Should the update fail, return to
step 4 when prompted and repeat the process.
Firmware Update
DSP firmware
LCD firmware
Upgrading device firmware, please
Wait !
UPGRADE FIRMWARE
Please Confirm
LVRT/HVRT Setup
Setting
P1/2
System Parameters
Protection Parameters
Power Derating Setup
Reactive Power Derating Setup
ARC Parameters
Control Command
History Record
Main Menu
Measurement Data
Power On/Off
Device Information
Setting
Setting
P2/2
Other Parameters
Firmware Update
File Export
UPGRADE FIRMWARE OK, PLEASE
WAIT!
UPGRADE FIRMWARE FAILURE,PLEASE
WAIT!
To Next Page
