Communication Setting
Baud rate： 9600
Address： 0001
Figure 5-7 Communication Setting
10. Setting the LCD contrast grade. From the previous menu, press ESC to
return to System Paramters menu. Select LCD Contrast Setting and
press ENT. Using the up/down arrows increase or decrease the contrast
to the desired setting. Press ENT to accept the changes.
11. When the LCD screen shows the normal operation status (Figure 5-8) and
the “RUN” light on the LED panel is illuminated, this is an indication that
the grid connection and power generation are successful.
E-T:0.0kWh
2015-10-22 12：00:00
E-D:0.0kWh
3
6 9 12 15 18 21 24h
15
30
45
60
kWh
Standby Addr:001
PV1:0.0V 0.0A
Figure 5-8 Normal Operation Status
