CPS SCA50KTL-DO/US-480 - Page 28

22
8"
MIN
8"
MIN
12"
MIN
BAFFLE
BAFFLE
12"
MIN
12"
MIN
12"
MIN
A)
B)
C)
D)
E)
14"
MIN
BAFFLE MUST:
1. EXTEND MIN. ABOVE AND BELOW FANS
2. EXTEND 4" MIN. PAST FRONT OF INVERTER
3. LOCATED 7" MIN. FROM BOTH INVERTERS
WALL OR
PASSIVE
CABINET
