Installation 9
Cat. No. 01029401
Mount the Valve
Figure 7.
1. Position large o-ring above threads.
Do not lubricate o-ring.
2. Lubricate small o-ring
3. Attach upper disperser by snap-
ping into the slots in the tank
adapter. Making sure, that it is
secured.
4. Twist the valve onto the
tank, counterclockwise
to the thread start. Twist
clockwise, handtight, until
the large o-ring is fully com-
pressed in the tank.
NOTE Tank may need to be rotated for
preferred positioning.
CAUTION! Do Not Overtighten!
NOTE For 24” Aqua-Sensor ported
tanks, replace o-ring included
with the valve with the thicker
o-ring provided with the
system.
