26 Culligan® Culligan Top Mount (CTM) Water Softeners
26 Cat. No. 01029401
Circuit Board - Motor and Position Sensor
POSITION
DC
MOTOR
FLOW
METER
RS485
BRINE
TANK
J22
2.5v
24v
AQUA SENSOR
AUX OUT4
AUX OUT3
AUX OUT2
AUX OUT1AUX INPUT
Figure 29.
1
2
34
Motor with Inverter
Position
Sensor
2 1
White
Brown
Black
Green
Red
12
34
2 1
