88 Culligan® Culligan Top Mount (CTM) Water Softeners
88 Cat. No. 01029401
24”, 30”, 39” and 42” Brine Systems
2
1
3
4
5
6
1
Figure 86. 24" and 30" brine systems.
1
3
2
5
6
4
1
Figure 87. 39” and 42” brine systems.
Item No. Part No. Description Qty Req.
01024800 24" x 50" Brine System Complete
01024801 30" x 50" Brine System Complete
01024802 39" x 48" Brine System Complete
01024803 42" x 48" Brine System Complete
1 Tank 1
2 Cover 1
3 01019623 Salt Plate Repl 24" 1
01019624 Salt Plate Repl 30" 1
01019625 Salt Plate, Screen & Supports 39" 1
01019626 Salt Plate, Screen & Supports 42" 1
4 01019621 Brine Well 1
5 01019622 Brine Well Cap 1
6 01029094 Brine Valve (3/4”), Replacement 1
— 01029095 Brine Valve Rebuild
— 01019620 Upper Clamp Kit for Valve
1
1
Clamp kit includes clamp, spacer, nuts, screws and washer.
