Installing Accessories 27
Cat. No. 01029401
Motor with Inverter
Installing Accessories
Multi-Tank Systems
Tubing Ball Valves for Multi-Tank Systems
For multiple units, motorized ball valves are installed and tubing connected to the Progressive Flow Top Manifold to alter-
nate the valves from Service to Standby. (See page 71 for more details.)
See page 20 for tubing the pilot valve.
Figure 30. Tubing to Ball Valve #1 (Ports 4, 5, 6) (Multi-Tank Softeners Only)
Feed
5
6
5
2
1
6
1
4
3
2
4
For the tubing connections, match up the
number ports. 1-1, 2-2, 3-3, etc...
To Next Page
