CTM Parts List 85
Cat. No. 01029401
CTM Piston Replacement Kit
Contains each of the 8 piston with the o-rings,T-seals and Flow Valves complete. Use this kit if you don’t want to change
all the individual o-rings on each piston. A Valve O-Ring Kit is also needed.
Item Part No. Description Qty
B 01029576 Piston Actuator w/O-Rings, Flow Valves and T-Seals Kit —
1 — Piston Actuator w/O-rings (2.63”) 4
2 — Piston Actuator w/O-rings (2.00”) 1
3 — Piston Actuator w/O-rings (1.50”) 2
4 — Piston Actuator Refill w/O-rings & Spring (1.50) 1
5 — Piston Flow Valve Kit w/T-seal (2.00 valve) 4
6 — Piston Flow Valve Kit w/T-seal (1.50 valve) 1
7 — Piston Flow Valve Kit w/T-seal (0.75 valve) 3
CTM Valve Core Replacement
Contains the center core with the pistons fully installed. Transfer the manifold, couplers, tank adapter, eductor assembly,
drain fitting, brine fitting, PRV, vacuum breaker and etc. A Valve O-Ring Kit is also needed
Item Part No. Description Qty
A 01029580 Valve Core Replacement Kit
—
1
— Core Valve Body 1
2 — Piston Actuator w/O-rings (2.63”) 4
3 — Piston Actuator w/O-rings (2.00”) 1
4 — Piston Actuator w/O-rings (1.50”) 2
5 — Piston Actuator Refill w/O-rings & Spring (1.50) 1
6 — Piston Flow Valve Kit w/T-seal (2.00 valve) 4
7 — Piston Flow Valve Kit w/T-seal (1.50 valve) 1
8 — Piston Flow Valve Kit w/T-seal (0.75 valve) 3
Pilot Valve Rebuild Kits
Item Part No. Description
—
01029583 Pilot Valve Rebuild Kit
1
—
Kit, Position Sensor
2
—
Kit, Pilot Body and O-Rings
3
—
Kit, Position Indicator Wheel
4
—
Gear, Pilot Drive Spool, CTM
