Installation 7
Cat. No. 01029401
Loading the Media
Table 3. Loading quantities.
Model
60K 90K 120K 150K 210K 300K 450K 600K
Cullex (Ft
3
)
2 3 4 5 7 10 15 20
Cullsan (lbs)
30 40 50 70 100 130 300 400
Freeboard (inches)
19 22 22 23 22 22 19 22
NOTE Do NOT attempt to load the media without having the tank in its final position. Moving the tank once
the media has been loaded will be difficult at best.
Figure 4.
1. Cover the top of the distributor pipe with
tape that will prevent media from entering
the distributor.
2. Use a funnel (P/N 01029516) in the opening to
add 6” of water to protect the distributor. Pour
Cullsan per Table 3, level before adding resin.
3. Pour bags of Cullex per Table 3.
4. Clean tank threads, remove tape and check for
any foriegn materials
NOTE Minimize the amount of water added
until final positioning of the tank
with the control valve mounted.
Freeboard
Cullex
Cullsan
