Culligan CTM Series User Manual

CTM Parts List 87
Cat. No. 01029401
18”x38” and 24”x40” Brine Systems
1
5
4
3
2
Figure 85. 18"x38" and 24"x40" brine systems.
Item
No.
Qty. Part No. Description
—
01019525
18” x 38” Brine System
Complete
—
01018720
24” x 40” Brine System
Complete
1 1 01018716 Tank Repl 18” x 38”
1 1 01018718 Tank Repl 24” x 48”
2 1 01018717 Cover Repl 18”
2 1 01018719 Cover Repl 24”
3 1 01018713 Salt Plate Repl 18”
3 1 01018714 Salt Plate Repl 24”
4 1 01018708 Brine Well with Cap
5 1 01019526 Brine Valve Repl 18" - 24” (1/2")
NOTE 18x38 and 24x40 brine systems may be used
with 60k and 90k units; the 0.80 flow control
must be removed from the brine valve for prop-
er operation. 120k and larger should use 3/4” or
larger brine valve.
