62 Culligan® Culligan Top Mount (CTM) Water Softeners
62 Cat. No. 01029401
Pilot Spool Replacement
1. Replace pilot valve spool (P/N 01029555).
2. Check o-rings to make sure they stay in place (or replace all 13 o-rings)
NOTE Make sure to that the position indicator dial is centered between the position sensor.
Figure 76.
