44 Culligan® Culligan Top Mount (CTM) Water Softeners
44 Cat. No. 01029401
To use Table 7 locate the resin volume of the softener model along the left side of the table. Select a 6, 10 or 15 pound/
cubic foot of resin salt dosage amount. Continue reading the table to the right until you find a brine system that provides
the salt storage characteristics desired. Refer to the key at the bottom of the chart for information concerning the shaded
areas of this table
Table 7. CTM Brinemaker Data
Softener
System
Resin Qty.
(ft
3
)
Salt
Dosage
Brine Tank Size (Diameter x Height) and Brine System Part Number
24”x50” 30”x50” 39”x48” 42”x48”
01024800 01024801 01024802 01024803
lbs/ft³
Max.
Salt
Load
No.
Regen
Max.
Salt
Load
No.
Regen
Max.
Salt
Load
No.
Regen
Max.
Salt
Load
No.
Regen
2
6 800 66.7 1200 100 1800 150 2400 200
10 800 40 1200 60 1800 90 2400 120
15 800 26.7 1200 40 1800 60 2400 80
3
6 800 44.4 1200 66.7 1800 100 2400 133.3
10 800 26.7 1200 40 1800 60 2400 80
15 800 53.3 1200 26.7 1800 40 2400 53.3
4
6 800 33.3 1200 50 1800 75 2400 100
10 800 20 1200 30 1800 45 2400 60
15 800 13.3 1200 20 1800 30 2400 40
5
6 800 26.7 1200 40 1800 60 2400 80
10 800 16 1200 24 1800 36 2400 48
15 500 6.7 1200 16 1800 24 2400 32
7
6 800 19 1200 28.6 1800 42.9 2400 57.1
10 524 7.5 1200 17.1 1800 25.7 2400 34.3
15 352 3.4 841 8 1800 17.1 2400 22.9
10
6 800 13.3 1200 20 1800 30 2400 40
10 376 3.8 866 8.7 1800 18 2400 24
15 619 4.1 1217 8.1 2400 16
15
6 426 4.7 1200 13.3 1800 20 2400 26.7
10 619 4.1 1217 8.1 2400 16
15 249 1.1 847 3.8 1554 6.9
XXX = wet storage (for more information regarding wet storage, see page 43)
= brine system or dosage not recommended for softener
Key for Table 8 on the Next Two Pages
Column Name Description
lbs/ft
3
= Salt Usage
Dos. = Salt Dosage
Cap. = Capacity
XXX = wet storage (for more information regarding wet storage, see page 43)
