Culligan CTM Series User Manual

Service and Repair 55
Cat. No. 01029401
Push all the pistons from the bottom and remove from the top side of the valve body.
Figure 64.
Load all pistons (8) in from the top and push to lower into the fully seated position. Flip the valve body onto its top (flow
valves up)
Figure 65.
CAUTION! Do NOT lubricate T-Seals!
Lubricate o-rings

Culligan CTM Series Specifications

General

Power Source	Electric
Voltage	120V
Type	Countertop
Dispensing Options	Cold
Filter Life	6 months
