CTM Parts List 83
Cat. No. 01029401
Item Part No. Description
— 01028301
Control Valve, Single Tank, Downflow, Hard
Water Bypass
— 01028304
Control Valve, Single Tank, Downflow, No
Hard Water Bypass
— 01028300
Control Valve, Multi Tank, Downflow, No
Hard Water Bypass
1
— —
Control Valve, Timeclock, Single Tank,
Downflow, No Hard Water Bypass
1 01029565 Kit, Brine Elbow Assembly
2 01000601 Insert, Refill Flow Control, 0.5 gpm
01000602 Insert, Refill Flow Control, 2.0 gpm
01000603 Insert, Refill Flow Control, 3.0 gpm
3 — Clip, Brine Adapter
3
4 P1028012 Clip, Drain Line Flow Adapter, 10 PK
3
5 01029469
Kit, Drain and Brine Line Flow Control, 60K
Units (Contains Items 2 and 6)
01029460
Kit, Drain and Brine Line Flow Control,
90K-600K Units (Contains Items 2 and 6)
6 P1028331
Inserts, Drain Line Flow Control, 0 GPM,
Black, 10 PK
P1028332
Inserts, Drain Line Flow Control, 5 GPM,
Blue, 10 PK
P1030741
Inserts, Drain Line Flow Control, 6 GPM,
Red, 10 PK
P1028333
Inserts, Drain Line Flow Control, 8 GPM,
Green, 10 PK
P1028334
Inserts, Drain Line Flow Control, 10 GPM,
Orange, 10 PK
7 01029581 No Hard Water Bypass Plug (for conversion)
8 01029564 Eductor Port Cap
9 P1028311
Eductor Nozzle, Black, w/O-Ring, 0.28 gpm,
10 PK
P1028313
Eductor Nozzle, Violet, w/O-Ring, 0.58 gpm,
10 PK
P1028314
Eductor Nozzle, Red, w/O-Ring, 0.72 gpm,
10 PK
P1028315
Eductor Nozzle, White, w/O-Ring, 1.01 gpm,
10 PK
P1028316
Eductor Nozzle, Blue, w/O-Ring, 1.44 gpm,
10 PK
P1028317
Eductor Nozzle, Beige, w/O-Ring, 2.16 gpm,
10 PK
10 P1028318
Eductor Throat, Blue #4, w/O-Rings, 2.4
gpm, 10 PK
P1028319
Eductor Throat, Blue #5, w/O-Rings, 3.6
gpm, 10 PK
P1028320
Eductor Throat, Blue #3, w/O-Rings, 5.9
gpm, 10 PK
P1028321
Eductor Throat, Blue #8, w/O-Rings, X gpm,
10 PK
11 — Clip, Eductor Plug Cap
3
12 01029567 Kit, Valve Clamp
13 P1023559 O-Ring, 10 PK
00401858 O-Ring (24”, 30” & 36” Ported Tanks Only)
Item Part No. Description
14 P1023560 O-Ring, 10 PK
15 P1023558 Retainer Ring, 10 PK
16 01019742 Upper Disperser
17 01028328 Kit, Flow Meter Assembly
2
01028052 Kit, Coupler Assembly
4
18 01029566 Kit, PRV Assembly
2
19 P1028381 Coupling/Flow Meter O-Ring, 10 PK
20 — Clip, Vacuum Breaker/PRV
3
21 01029582 Vacuum Breaker & PRV Port Plug
22 01029580 Kit, Core Control Valve Replacement
23 01029584 Screws, Top Manifold
5
and Pilot Enclosure
24 01029562 Motorized Ball Valve #1 (Ports 4, 5, 6)
1
25 01029563 Motorized Ball Valve #2 (Ports 1, 2, 3)
1
26 01029583 Pilot Valve Rebuild Kit
27 — Kit, Position Sensor
3
28 — Kit, Pilot Body and O-Rings
3
29 — Kit, Position Indicator Wheel
3
30 — Gear, Pilot Drive Spool, CTM
3
31 01029558 Kit, Motor Assy, CTM
32 01029560 Housing, Top, Pilot Body, Downflow
33 01029561 Kit, Enclosure, Pilot Drive
34 01029576
Kit, Piston Actuator w/O-Rings, Flow Valves
and T-Seals
35 01029577 Kit, Piston O-Rings and T-Seals
36 01029578
Kit, Seals for upper, lower and external
valve body
37 01029580 Valve Core Replacement Kit
38 01029500 1.5” NPT Inlet/Outlet Plumbing Adapter
01029502
1.5” NPT Inlet/Outlet Plumbing Adapter w/
Ports
01029512 1.5” BSPT Inlet/Outlet Plumbing Adapter
01029514
1.5” BSPT Inlet/Outlet Plumbing Adapter w/
Ports
01029501 2” NPT Inlet/Outlet Plumbing Adapter
01029503
2” NPT Inlet/Outlet Plumbing Adapter w/
Ports
01029513 2” BSPT Inlet/Outlet Plumbing Adapter
01029515
2” BSPT Inlet/Outlet Plumbing Adapter w/
Ports
39 00303177 Tubing, 1/4”, PE Black, 1 ft. (for Pilot Valve)
5
00402184 Tubing, 1/4”, PE Blue, 1 ft. (for Pilot Valve)
5
40 01030179 Cable Harness, Ball Valves, Valve Mount
1, 5
01030177
Cable Harness, Ball Valves, Remote
Mount
1, 5
41 01028019 Kit, Clips (Contains Item 3, 4, 11, and 20)
42 01029550
Kit, Single to Multi Tank Manifold
Conversion
5
1
Multi-Tank Only
2
Not designed to operate with Timeclock Control Valves.
3
A part of a Kit
4
Timeclock Only
5
Not Shown
To Next Page
