FEATURES
High Port Density
Up to 20 Gigabit Ethernet Switch ports in single-slot PCI/104-Express form factor (3.6”x3.8”) card;
8-port option also available.
Rugged Design
-40/+85C extended-temperature operation, vibration-tolerant connectors for cableless/cabled
network connections, staked and underfilled components.
Carrier Grade
Carrier Ethernet (CE) Switch Engine with embedded 32-Bit Management Processor.
CE Services Software delivers Rich Layer-2 Switch Features, Layer 3-Aware Packet Processing,
Service Classification and Traffic Policing; IEEE-1588 Precision Timing Protocol and Hardware
Accurate Timestamping.
Layer 2 Switching
10/100/1000 Mbps Gigabit Ethernet connectivity, IPv4/IPv6 Multicast, VLAN, QoS/CoS Traffic
Prioritization, Multiple/Rapid Spanning Tree, Link Aggregation, IEEE-1588 Sync.
Layer 3 Routing:
Layer 3 IPv4 / IPv6 Unicast Static Routing Support for IP Routing to Attached WAN / Radio Ports.
Management
SNMPv3, HTTP Server, Web GUI, RS-232 Console CLI, Port Monitoring, RMON, Syslog,
Network Access Server (NAS), 802.1X Authentication, IGMP Snooping, Access Control Lists
(ACLs), Zeroization, Built in Test (BIT) Diagnostics.
Declassification
Data Zeroization support for secure data (initiated by off-board signal trigger).
Low Power
Energy-efficient Ethernet (IEEE-802.3AZ) support with low-power PHYs and smart cable reach
technology for extremely low power consumption.
Bus or External Powering
Can be powered via PCI-104 (PCI) bus, PCIe104 (PCI Express) bus, or auxiliary power
connector for standalone operation.
Integration Flexibility
Two connector options (Harwin, Molex) to support either hand-crimping CAT5e cabling or card-to-
card (cableless) interface for Ethernet ports.
