Curtiss-Wright Parvus SWI-22-10-10 User Manual

MNL-0641-01 Rev A3
ECO-4823
Effective: 04 Oct 16
Page 91 of 107
ADVANCED CONCEPTS
UNDERSTANDING MODES AND SUB-MODES
The CLI implements a number of modes that control the available command set. The modes are further
influenced by the privilege level of the user; some modes or commands are only accessible to
administrators while others require no privileges beyond log in.
There are three major modes, Exec, Privileged Exec and Config. Under Config are a number of sub-
modes. The sub-modes allow configuration of specific VLANs, Ethernet interfaces, etc.
Mode
Parent Mode
Description
Exec
-
Lowest-privileged mode; used for basic system monitoring. Generally does not
allow modifications to the system.
Command: disable
Prompt: hostname>
Privileged Exec
Exec
Privileged mode; allows configuration and other modifications to the system.
Command: enable
Prompt: hostname#
Config
Privileged Exec
Global configuration mode
Command: configure terminal
Prompt: hostname(config)#
VLAN config
Config
Sub-mode for configuring active VLANs
Command: vlan vlan_id_list
Prompt: hostname(config-vlan)#
VLAN interface config
Config
Sub-mode for configuring VLAN interfaces
Command: interface vlan vlan_id_list
Prompt: hostname(config-if-vlan)#
Interface config
Config
Sub-mode for configuring Ethernet interfaces
Command: interface type switch_num/port_num
Prompt: hostname(config-if)#
Line
Config
Sub-mode for configuring terminal lines
Command: line { con | vty } line_num
Prompt: hostname(config-line)#
IPMC Profile Config
Config
Sub-mode for configuring IP Multicast profiles
Command: ipmc profile profile_name
Prompt: hostname(config-ipmc-profile)#
SNMP Server Host Config
Config
Sub-mode for configuring SNMP server host entries
Command: snmp-server host host_name
Prompt: hostname(config-snmps-host)#
STP Aggregation Config
Config
Sub-mode for configuring Spanning Tree Protocol aggregation
Command: spanning-tree aggregation
Prompt: hostname(config-stp-aggr)#
DHCP Pool Config
Config
Sub-mode for configuring DHCP client pools
Command: ip dhcp pool pool_name
Prompt: hostname(config-dhcp-pool)#
RFC2544 Profile Config
Config
Sub-mode for configuring RFC2544 profiles
Command: rfc2544 profile profile_name
Prompt: hostname(config-rfc2544-profile)#
