CHAPTER 6 SPECIFICATIONS
GENERAL SPECIFICATIONS
APPLICATIONS
Small form factor embedded systems, including standalone or stacking architectures (i.e.,
PC/104-Plus, PCI-104, PCIe/104, PCI/104-Express, EBX, EPIC)
High-speed Gigabit Ethernet Local Area Network (LAN) switching for IP-enabled equipment, such
as onboard computers, cameras, sensors, monitoring devices, and command-and-control gear in
harsh temperature and vibration environments
Size, Weight & Power (SWaP) sensitive mobile, tactical, airborne, and vehicle applications for
situational awareness and network centric operations
BREAKOUT CABLE SET
Optional breakout cable set mates with onboard Ethernet and power connectors and transitions
to RJ-45, RS-232, and power supply connectors (for lab/testing purposes)
TECHNICAL SPECIFICATIONS
This section describes the technical specifications of the SWI-22-10.
POWER
Power Input: 5VDC (via PCI bus / PCI Express Bus); 3.0-5.5VDC (via Auxiliary Power
Connector, measured at the connector)
Power Consumption: < 14W maximum (all 20 ports actively driving 100-meter cables with full-
bandwidth traffic)
Support for Energy Efficient Ethernet (IEEE 802.3az) in Switch Core and PHYs
SWITCHING ARCHITECTURE
Packet Processor: Highly Integrated Vitesse Carrier Grade Ethernet Switch Engine
Switching: Non-Blocking Layer 2, IPv4 / IPv6 Multicast, Low-Latency, Auto-MDI/MDIX, Auto-
Negotiation, Auto-Detect; Speed Auto-Sensing, Auto-Crossover, Full/Half Duplex Modes
Management Processor: Embedded 32-Bit MIPS CPU @ 416MHz with DDR-2 Memory
Networking Software: Vitesse CEServices Carrier Ethernet application running on eCos operating
system for optimal performance and Redboot bootloader for reliability
