User's Manual
8
No. Port Function Description
4 ALARM Alarm port
●
Alarm output, connecting to barrier, and
alarm output devices such as alarm light.
◇
Brown: ALARM_NO1
◇
Green: ALARM_COM1
◇
White & Purple: ALARM_NO2
◇
Light Green: ALARM_COM2
◇
Red: ALARM_NO3
◇
Black: ALARM_COM3
●
Alarm input, connecting to vehicle
detector, IR detector, induction loop, and
more.
◇
Blue: ALARM_IN1
◇
White: ALARM_IN2
◇
Yellow: ALARM_IN3
◇
Gray: ALARM_IN_GND
5 24 VAC Power input port
Inputs 24 VAC power. Be sure to supply
power as instructed.
Device damage will occur if power is not
supplied correctly.
6 LAN Ethernet port
Connects to standard Ethernet. Supports PoE
power supply.
7 12 VDC Power input port
Inputs 12 VDC power. Be sure to supply
power as instructed.
Device damage will occur if power is not
supplied correctly.
8 BNC Video output port
The Camera sends out video signal through
this port.
