Dahua MCVR6204 User Manual

Web Operations 148
Select SETUP > SYSTEM > PTZ. Step 1
The PTZ interface is displayed.
Select a channel.
Step 2
In the PTZ Type list, select PTZ type, and then configure other parameters. Step 3
 If Channel 1 to Channel 8 is selected, the PTZ type is Local by default which
cannot be modified. See Figure 5-28. Configure the parameters. For details, see
Table 5-9.
PTZ settings (Local) Figure 5-28
Table 5-9 PTZ settings parameter parameters description
Parameter
Description
Channel
Select a channel that is connected to PTZ camera.
Protocol
Select the protocol that matches the PTZ camera.
Address
Enter the address for PTZ camera.
The entered address must be the same with the address configured on
the PTZ camera; otherwise the PTZ camera cannot be controlled from
the Device.
Baud Rate
Select the baud rate for the PTZ camera.
Data Bit
The default value is 8.
Stop Bit
The default value is 1.
Parity
The default value is None.
 If Channel 9 to Channel 12 is selected, in the PTZ Type list, select Remote. See
Figure 5-29.
PTZ settings (Remote) Figure 5-29
Click Save. Step 4
Click Copy to copy the settings to other channels.
