Dahua MCVR6204 User Manual

Web Operations 165
Parameter
Description
Smart Code
Enable the smart code function. This function can reduce the video bit
stream to maximize the storage space.
Resolution
In the Resolution list, select the video resolution. The higher the value is, the
better the image quality will become.
Frame Rate
(FPS)
Configure the frames per seconds for video. The larger the value is, the
smoother and more vivid the image will be.
Bit Rate
Type
Select a control mode for bit rate of video.
CBR: Constant Bit Rate, which changes around the configured value.

VBR: Variable Bit Rate, which changes along with environment.

It is recommended to select CBR when there might be only small changes in
the monitoring environment, and select VBR when there might be big
changes in the monitoring environment.
Bit Rate
Configure the encode value for main stream and sub stream.
When CBR is selected, select the bit rate according to the reference bit

rate, and the bit rate changes along the configured value.
When VBR is selected, select the upper limit value of bit rate according

to the reference bit rate, and the bit rate changes along with the
monitoring environment. But the maximum bit rate value changes
around the configured value.
Select Customized, you can manually enter Bit Rate information in the

box.
Quality
This function is available if you select VBR in the Bit Rate list.
Select the image quality level. The higher the value, the better the image will
become.
Reference
Bit Rate
The system recommends the optimal bit rate range according to the
resolution and frame rate settings.
Audio
Enable
If the Audio Enable check box is selected, the recorded video file is
composite audio and video stream.
Audio
Format
Select an audio encode format.
The parameters might be different depending on the model you purchased,
and the actual product shall prevail.
Audio
Source
This parameter is available when Channel 1 is selected. The audio source
includes HDCVI camera and external pickup.
Watermark
Enable
Select the Watermark Enable check box to verify whether the recorded
video is falsified.
Watermark
String
Enter the strings for verifying watermark. The default string is Digital CCTV.
The watermark string can consist of number, letter, underline (_), and
strikethrough (-), and maximum length contains 127 characters.
Click Save. Step 4
5.3.1.2.2 Configuring Snapshot Settings
You can configure the snapshot settings such as snapshot type, image size, quality, and
interval.
