Local Configurations 51
4.2.2.6 Entering PTZ Menu
If the remote device supports OSD menu, you can open the OSD menu from the Device to
perform the corresponding configurations. This function is supported only on Channel 9 to
Channel 12.
On the PTZ control panel, click Pg Switch till the PTZ menu configuration interface is Step 1
displayed.
The OSD menu is displayed on the screen, see Figure 4-36. For details, see Table
4-15.
PTZ OSD menu Figure 4-36
Table 4-15 PTZ menu parameters description
Click Enter Menu, the OSD menu is displayed on the channel window.
Click Exit
Menu, the OSD
menu closes.
Click Exit Menu, the OSD menu closes.
Click or to move the pointer to the item you want to configure on
the OSD menu.
When the pointer has selected an item, click or to configure this item.
If there is sub-menu for an item, click Enter to enter the sub-menu.
More the pointer to Return, and then click Enter to return to the
higher level menu.
More the pointer to Exit, and then click Save to exit the OSD menu.
Click Esc to cancel the OSD menu operations.
Click Enter Menu. Step 2
The OSD menu is displayed on the screen, see Figure 4-37. For details, see Table
4-16.
