Dahua MCVR6204 User Manual

Local Configurations 50
Function
Operation
Calling
AutoPan
Click AutoPan, the PTZ camera keeps horizontal rotating by 360°. Click
Stop to stop rotating.
Using Flip
function
Click Flip to turn the image upside down (180°).
Reset
Click Reset to restore the camera to the default position.
4.2.2.5 Auxiliary Functions
On the PTZ control panel, click Pg Switch till the auxiliary functions setting interface is
displayed. See Figure 4-35. For details, see Table 4-14.
Auxiliary Functions Figure 4-35
Table 4-14 Auxiliary function parameters description
Parameter
Description
Direct Aux
Controls the light of external device through RS-485 command. To use

this function, make sure it is supported on the external device.
In the function list, select Light. Click On to turn on the light, and click
Off to turn off the light.
Controls the screen wiper of external device through RS-485 command.

To use this function, make sure it is supported on the external device.
In the function list, select Screen Wiper. Click On to turn on the screen
wiper, and click Off to turn off the screen wiper.
Controls the warming-up module of external device through RS-485

command. To use this function, make sure it is supported on the
external device.
In the function list, select Clear fog. Click On to turn on the fog clearing,
and click Off to turn off the fog clearing.
Aux Num
In the Aux Num box, enter a number that corresponds to the AUX switch on
the decoder. Click On to turn on the auxiliary number function, and click Off
to turn off the auxiliary number function.
PONE
Select the PONE check box, the PTZ camera first turns to the configured
preset when it is turned on.
POFE
Select the POFE check box, the PTZ camera first turns to the configured
preset when it is turned off.
