To document immunity against burst transient from electrical phenomena, the following immunity tests have been made on a system
consisting of:
l A drive (with options if relevant).
l A shielded control cable.
l A control box with potentiometer, motor cable, and motor.
The tests were performed in accordance with the following basic standards:
l EN 61000-4-2 (IEC 61000-4-2) Electrostatic discharges (ESD): Simulation of electrostatic discharges from human beings.
l EN 61000-4-3 (IEC 61000-4-3) Radiated immunity: Amplitude modulated simulation of the effects of radar and radio
communication equipment and mobile communications equipment.
l EN 61000-4-4 (IEC 61000-4-4) Burst transients: Simulation of interference caused by switching a contactor, relay, or similar devices.
l EN 61000-4-5 (IEC 61000-4-5) Surge transients: Simulation of transients caused by, for example, lightning that strikes near
installations.
l EN 61000-4-6 (IEC 61000-4-6) Conducted immunity: Simulation of the effect from radio-transmission equipment joined by
connection cables.
The immunity requirements should follow product standard IEC 61800-3. See Table 36 for details.
Table 36: EMC Immunity
Product standard 61800-3
Test ESD Radiated
immunity
Burst Surge Conducted
immunity
Acceptance criterion B A B B A
Mains cable – – 2 kV CN 1 kV/2 Ω DM
2 kV/12 Ω CM
10 V
RMS
Motor cable – – 2 kV CCC – 10 V
RMS
Brake cable – – 2 kV CCC – 10 V
RMS
Load sharing cable – – 2 kV CCC – 10 V
RMS
Relay cable – – 2 kV CCC – 10 V
RMS
Control cable – – Length >2 m (6.6 ft)
1 kV CCC
Unshielded: 1 kV/42
Ω CM
10 V
RMS
Standard/fieldbus cable – – Length >2 m (6.6 ft)
1 kV CCC
Unshielded: 1 kV/42
Ω CM
10 V
RMS
Control panel cable – – Length >2 m (6.6 ft)
1 kV CCC
– 10 V
RMS
Enclosure 4 kV
CD
8 kV
AD
10 V/m – – –
Definitions
CD: Contact discharge
AD: Air discharge
DM: Differential mode
CM: Common mode
CN: Direct injection through coupling network
CCC: Injection through capacitive coupling
clamp
