Gryphon™ I GD44XX/GBT4400/GM440X

Code 128 Set Length 1

Specifies one of the bar code lengths for Code 128 Length Control. Length 1

is the minimum label length if in Variable Length Mode, or the first fixed

length if in Fixed Length Mode. Length includes the bar code’s data charac-

ters only. The length can be set from 1 to 80 characters.

Table 5 provides some examples for setting Length 1. See page 283 for

detailed instructions on setting this feature.

Table 5. Code 128 Length 1 Setting Examples

STEP ACTION EXAMPLES

1 Desired Setting

01 Character 07 Characters 15 Characters 80 Characters

2 Scan ENTER/EXIT PROGRAMMING MODE

3 Scan SELECT CODE 128 LENGTH 1 SETTING

Scan Two Characters From

Appendix D, Keypad

‘0’ and ‘1’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘8’ AND ‘0’

5 Scan ENTER/EXIT PROGRAMMING MODE

$CC8L1

Select Code 128 Set Length 1 Setting

Make a mistake? Scan the CANCEL bar code to abort

and not save the entry string. You can then start again

at the beginning.

CANCEL

DEFAULT

01 = Length 1 is 1 Character
